Granite Fabrication Tables & Stands

The table requires a single-phase electrical supply of 208–240 volts at 25 amps, which must comply with local electrical codes. It also requires a compressed air supply between 80–120 PSI from your shop's air system. Both utilities are standard in most professional stone fabrication shops and should be verified before installation.

The air-cylinder powered indexer pulls the table to exact 90° and 45° angles for repeatable, precise cuts. The brake valve locks the table at any angle, allowing fabricators to make custom angled cuts beyond the standard presets. This combination ensures consistent results across high-volume production runs.

The hydraulic powered lift can raise slabs up to 70 degrees. It is capable of supporting multiple slabs simultaneously, making it well-suited for high-volume countertop fabrication facilities. This allows operators to load, position, and process large stone slabs safely without additional manual lifting equipment.

The standard table top size is 126" x 77". Optional widths of 132" or 138" are available on request to accommodate wider slab configurations. The table ships with a 30-foot air hose between the valves and the table. Contact Crown Stone USA to discuss custom sizing options for your specific shop layout.

The table requires greasing every 2 months as the primary scheduled maintenance task. The CNC machined rolling surfaces and moisture-avoiding design are built for long-term reliability with minimal upkeep. Crown Stone USA provides maintenance guidance with every table and offers direct contact support for any service questions that arise.

Yes, the Crown Stone USA Bridge Saw Table is manufactured in the USA. Crown Stone USA sources less than 2% of components by value from China, with parts primarily sourced from the U.S., North and South America, Korea, Japan, and Taiwan. A manufacturer warranty is included with every table, and full warranty terms are available on request.
